Gallmac CMW-70
The Gallmac CMW-70 tracked multipurpose excavator combines full hydraulic load sensing, dual variable displacement pumps, heavy-duty 45-element tracks, and Perkins diesel power.
Gallmac CMW-70 Engineering Specification Table
| Subsystem | Engineering Parameter | US Standard (Imperial) | Metric (SI Units) |
|---|---|---|---|
| Engine | Engine Make & Model | Perkins 704-30 4-Cylinder direct injection | Perkins 704-30 4-Cylinder direct injection |
| Engine | Max Power | 47 kW (63 HP) at 2,600 RPM | 47 kW (63 HP) at 2,600 RPM |
| Transmission | Travel Speeds (1st / 2nd) | 1.6 mph / 2.8 mph | 2.5 km/h / 4.5 km/h |
| Undercarriage | Standard Track Width & Ground Pressure | 16 in. (0.39 daN/cm2) | 400 mm (0.39 daN/cm2) |
| Undercarriage | Overall Track Length | 115 in. | 2,920 mm |
| Hydraulics | Pump Flow & Working Pressure | 122 qts./min at 270 bar | 115 lt/min at 270 bar |
| Dimensions | Max Height | 111 in. | 2,800 mm |
| Dimensions | Max Width | 87 in. | 2,200 mm |
| Dimensions | Max Length | 173 in. | 4,400 mm |
| Weight | Weight as Digging Machine | 15,432 lbs. | 7,000 kg |
| Weight | Weight as Elevator | 15,653 lbs. | 7,100 kg |
| Digger | Bucket Width Range | 12 to 35 in. | 300 to 900 mm |
| Digger | Teeth Breaking Force | 12,412 lbs. | 5,630 kg |
| Elevator | Forks Capacity (Max / Min Radius) | 2,205 lbs. / 3,968 lbs. | 1,000 kg / 1,800 kg |
| Elevator | Hook Capacity (Max / Min Radius) | 2,866 lbs. / 6,173 lbs. | 1,300 kg / 2,800 kg |
